Chapter 4 The Mk7A Meter
This chapter covers the basic installation and physical features of the Mk7A meter.
Dimensions and Mounting
Figure 4-1 shows the overall dimensions of the meter with a standard terminal cover.
Height
Depth
Width
• Figure 4-1 Overall dimensions of the meter
Height = 233 mm, Depth = 85 mm, Width = 128 mm
