EDMI Atlas Mk7 - Chapter 5 The Mk7 C Meter

The Mk7C Meter 5-1
C h a p t e r
5
Chapter 5 The Mk7C Meter
This chapter covers the basic installation and physical features of the Mk7C meter.
Dimensions and Mounting
Figure 5-1 shows the overall dimensions of the meter with a standard terminal cover.
Depth
Width
Height
• Figure 5-1 Overall dimensions of the meter
Height = 163.5 mm, Depth = 51 mm, Width = 134 mm
