Service, spares and accessories
B756-01-880 Issue K
7.4.4 Pump-to-controller cables
A pump-to-controller cable must be fitted between an EXC Controller and the EXT Split Flow Pump. A cable is not
supplied with the EXT Split Flow Pump or the EXC Controller (except EXC100L). The following cables are available:
7.4.5 EXT water cooling block assembly
A water cooler can be fitted to the EXT Split Flow Pump. However please refer to Section 2.4 to check the stability
of the cooling-water supply:
7.4.6 TAV vent valve and vent port adaptor
Two solenoid-operated vent valves are available for system venting. The valves are 24 V d.c., normally-open, and
can be driven automatically from the EXC Controller. The solenoid valve is fitted in place of the manual valve, or
alternatively can be fitted with an adaptor (supplied with the valve) and be used with any suitable NW10 flanged port
on the vacuum system. The vent port adaptor allows the vent port or the purge port to be used with any suitable
NW10 fitting.
7.4.7 ACX air cooler
An ACX air cooler can be fitted to the EXT Split Flow Pump. However, please refer to Section 2 to check the suitability
of air cooling in a particular application.
Table 13 - Pump-to-controller cable
Cable Length Item Number
Pump-to-controller 1 m D396-18-010
Pump-to-controller 3 m D396-18-030
Pump-to-controller 5 m D396-18-050
Table 14 - EXT water cooling block assembly
Water cooler Item Number
WCX250M B735-01-164
Table 15 - TAV vent valve and vent port adaptor
Product Item Number
TAV5 vent valve B580-66-010
TAV6 vent valve B580-66-020
NW10-1/8 inch BSP male adaptor B580-66-011
NW10-1/8 inch BSP male extended vent port adaptor B580-66-028
Table 16 - ACX air cooler
Air cooler Item Number
ACX250H B580-53-160
