Edwards iXM1200 Standard

Figure 13 Coding pin conguraon
Figure 14 Mains connector on pump bulkhead
Pin idencaon
Pin A1 Phase 1
Pin A2 Phase 2
Pin B1 Phase 3
Pin B2 Not connected
Pin PE Protecve earth
10/2020 - ©Edwards Limited
Page 41M56635880_D
