Edwards iXM600 Standard

Figure 11 Mains input supply connector
1. Cable gland 2. Hood
3. 3-Phase main cable 4. Earth
5. Protecve earth 6. B1
7. A2 8. A1
9. Connector block 10. L2
11. L1 12. L3
1. Cable gland 2. Hood
3. 3-Phase main cable 4. Earth
5. Protecve earth 6. B1
7. A2 8. A1
9. Connector block 10. L2
11. L1 12. L3
Torque sengs for c
onnector pins
Cable size (mm
2
)
Maximum torque seng (Nm)
6 2
10 3
Figure 12 Method for connecng phase wir
es
10/2020 - ©Edwards Limited
Page 40M56635880_D
M56635880_D - Inst
allaon
