Edwards iXM600 Standard

Figure 15 Mains input supply connector - Han® K 4/4
A. Low volt pin con
guraon B. High volt pin conguraonA. Low volt pin conguraon B. High volt pin conguraon
1. Mounng screw 2. Coding pin
3. Insert stranded wire 4. 2.5 mm hex (Allen) key
1. Mounng screw 2. Coding pin
3. Insert stranded wire 4. 2.5 mm hex (Allen) key
Pin idencaon
Pin 1 Phase 1
Pin 2 Phase 2
Pin 3 Phase 3
Pin 4 Not connected
PE Protecve earth
Torque sengs for connector pins
Cable size (mm
2
)
Maximum torque seng (Nm)
6 2
10 3
16 4
