NORMAFIX
8
Cubicle CIS
1- Accessories for lifting the cubicle
2- Low voltage compartment
3- Mechanical synoptic state of the switch disconnector
4- Earth switch operating mechanism
5- Switch disconnector operating mechanism
6- Live cables signalling neon lamps
7- MV Cables acess painel
8- Earth circuit
9- Busbar access panel
10-Busbar deflector
11- ISF Switch Disconnector
12- Fire system protection fuse
13- Upper fuse support
14- MV Fuses
15- Bottom fuse support
16- Capacitive insulator of support
17- Additional Earth switch
18- MV Cables
19- Tightening of cables
9
18
10
19
7
4
2
1
11
12
14
5
6
3
8
15
13
16
17
