EFD 1500XL User Manual

1500XL CONTROLS & CONNECTIONS
10
❸
❷❼
Male quick-connect,
insert and twist to lock
Blue
test fluid
❶
❹
❻
❺
Note: The controls for the 1500XL, -15 and -CA models are identical.
Voltage selector and
fuse cartridge
Power
switch
Foot pedal
receptacle
Air input
I/O 9 pin
interface
connector
Vacuum transducer/
air exhaust port
Power input
receptacle
Air pressure
regulator
Barrel
vacuum control
Vacuum gauge
Air output
quick-connect
Time set buttons
Display and
control pad
( Refer to pages 6-7 for
detailed instructions.)
Air gauge

EFD 1500XL Specifications

General

Brand	EFD
Model	1500XL
Category	Dispenser
Language	English
