Getting Started
We have organized this Guide to provide setup and testing proce-
dures for the 1500 Series dispensers.
If you have the 1500XL, 1500XL-15 or 1500XL-CA, first review
pages 8 - 11 which illustrate how to hook up the dispenser and what
the controls do.
For the 1500DV or 1500DV-15, review pages 12 - 15.
If you have the 1500D, review pages 16 - 19.
Next, pages 20 - 21 show how to dispense the thick paste-like test
material included in the Test Kit. These instructions are common to
the 1500XL, 1500DV and 1500D dispensers.
Finally, pages 22 - 23 illustrate how to dispense low viscosity fluid
using the vacuum control. These instructions are common to the
1500XL, 1500XL-15, 1500XL-CA, 1500DV and 1500DV-15
dispensers.
The rest of the information in this Guide applies to all of the 1500
Series dispensers.
4
Specifications
Input Voltage: Selectable
100/120/220 VAC
50/60Hz
1500XL
1500XL-15
1500XL-CA
1500DV
1500DV-15
1500D 14/12VA
Internal Voltage: 24 VDC
Foot Pedal Voltage: 5.5 VDC
Cycle Rate: >600/minute
Time Control: microprocessor with
0.00005 second repeatability
Time Range: programmable
0.001 to 99.9 seconds
Initiation: momentary
Air Input: 80 to 100 psi
(5.5 to 6.9 bar)
Air Output:
1500XL, 1500DV, 1500D
0 to 100 psi (0 to 6.9 bar)
1500XL-15, 1500XL-CA, 1500DV-15
0 to 15 psi (0 to 1.0 bar)
1500XL, 1500XL-15, 1500XL-CA
10⅜ x 8½ x 2⅝˝ 4 lb 14 oz
(26.4 x 21.6 x 6.7 cm) (2.21 kg)
1500DV, 1500DV-15
10⅜ x 8½ x 2⅝˝ 5 lb 2 oz
(26.4 x 21.6 x 6.7 cm) (2.32 kg)
1500D
8⅝ x 8½ x 2⅝˝ 4 lb 2 oz
(21.9 x 21.6 x 6.7 cm) (1.87 kg)
14/12VA
18/15VA
