EFD 1500XL User Manual

12
❷
❼
Blue
test fluid
Check voltage label
on dispenser
❸
A
B
❽
Vacuum
pickup pen
Pickup tip
❶
Plant air, 125 psi maximum to
regulator. Output from regulator
should be a minimum of 80 psi,
maximum of 100 psi.
Foot pedal assembly
Power cord
Air input
hose
Adapter
assembly
❻
❹
❺
Note: For hookup purposes,
the connections for the
1500DV and 1500DV-15
models are identical.
Male quick-connect,
insert and twist to lock
1500DV
