EFD 1500XL - 1500 D Controls and Connections Layout

1500D CONTROLS & CONNECTIONS
18
❸❷
❶
❺
❹
Voltage selector and
fuse cartridge
Air gauge
Power
switch
Foot pedal
receptacle
Air input
I/O 9 pin interface
connector
Power input
receptacle
Air pressure
regulator
Air output
quick-connect
Time set buttons
Display and
control pad
( Refer to pages 6-7 for
detailed instructions.)
