EFD 1500XL User Manual

8
❸
❷
Check voltage label
on dispenser
❼
Male quick-connect,
insert and twist to lock
Blue
test fluid
❶
Plant air, 125 psi maximum to
regulator. Output from regulator
should be a minimum of 80 psi,
maximum of 100 psi.
Power cord
Air input
hose
Adapter
assembly
❹
❻
❺
Foot pedal
assembly
1500XL
Note: For hookup purposes,
connections for the 1500XL,
1500XL-15 and 1500XL-CA
models are identical.
