USER MANUAL
15EN
EN
TRIUMPHATOR 1700X / 1800X
14
ASSEMBLING THE THREAD STAND
The overlock comes with the thread guide stand in the lowest position.
Raise the thread guide stand to the highest position. Then adjust the posi-
tion of the thread guide.
THREAD SPOOL CONSERVERS
THREAD SPOOL NET
The conserver is used to x the thread spool on the
overlock rod.
1. Thread spool conserver.
Loosely wound polyester or nylon threads will loosen
when they come off the spool. To maintain a constant
feed rate of such threads, put a net over the spool.
1. Net.
GATHERING FABRIC
The differential feed mechanism makes it easier to gather lightweight fab-
rics. Use it to sew waist seams, seam sleeves, hem sleeves and cuffs, etc.
For best results when gathering fabrics, set the differential feed control
between the 1.5 and 2 marks.
FLAT SEAM
Clothing without wavy lines
WAVY SEAM
Wavy edge fabrics (without jamming)
GATHER
Gathering fabrics
UNEVEN SEAM
Fabric Jam (No Gathering)
