Accessing the Fiery X3eTY

7. With the Fiery X3eTY on a ﬂat surface, remove the 11 screws that secure the pan cover to

the pan (see Figure G).

8. Open the lid, slide the tabs out of their slots and lift the pan cover from the pan

(see Figure G).

Set the pan cover and screws aside.

FIGURE G Fiery X3eTY pan cover screws

The Fiery X3eTY is now ready for inspection and service.

Tab (1 of 3)

Slot (1 of 3)

Pan cover

Pan
