Max. charging power per day 600 Wh/day 1560 Wh/day 2160 Wh/day 2160 Wh/day
Nominal power 25 W 65 W 90 W 90 W
Nominal voltage 12 V / 24 V 12 V / 24 V 12 V / 24 V 12 V / 24 V
Nominal charging current at 12 V/24 V 2.1 A / 1.05 A 5.4 A / 2.7 A 7.5 A / 3.75 A 7.5 A / 3.75 A
Recommended
battery capacity*
at 12 V
at 24 V
10 to100 Ah
5 to 50 Ah
40 to 250 Ah
20 to 120 Ah
60 to 350 Ah
30 to 175 Ah
60 to 350 Ah
30 to 175 Ah
Weight
6.8 kg
(15 lbs)
8.3 kg
(18.3 lbs)
8.6 kg
(19 lbs)
8.95 kg
(19.7 lbs)
Switching threshold for automatic
battery charging at 12 V /24 V **
On: <12.3 V / <24.6 V
Off: >14.2V / >28.4 V
Required start-up voltage at 12 V /24 V >9 V / >18,5.0 V
Noise level (at 1m / 7m distance) 39 / 23 dB(A)
Nominal consumption*** 0.9 l/kWh (0.2 imp gal/kWh)
Quiescent current draw 15 mA
Operating temperature -20 °C to +45 °C (-4°F to +113°F)
Start-up temperature +5 °C to +45 °C (41°F to 113°F)
Storing temperature +1 °C to +45 °C (34°F to 113°F)
Recommended altitude Up to 1500 m (4920 ft)
Dimensions L x W x D 433 x 188 x 278 mm (17.0 x 7.4 x 11.0 in)
Inclination around the roll axis Permanent: max. 35°; temporary (<10 min): max. 45°
Inclination around the lateral axis Permanent: max. 20°
User-Interface At the unit or via Remote Control with text display
Data-Interface RJ-45 plug for accessories (e.g. Interface adapter)
Electrical Interface MNL-plug 4-pins (e.g. Tyco Electronics Universal Mate-N-Lok – Nr. 350779)
* Depends on battery type and application - bigger batteries possible, if charging current sufficient (e.g. solar battery)
** Factory Setting - can be modified with Interface Adapter and PC
*** Effective consumption depends on operating conditions
Fuel Cartridges M5 M10 M28 (requires M28 adapter)
Volume 5 l (1.1 imp gal) 10 l (2.2 gal) 28 l (6.2 imp gal)
Weight 4.3 kg (9.5 lbs) 8.4 kg (18.5 lbs) 22.0 kg (48.5 lbs)
Nominal capacity 5.5 kWh 11.1 kWh 31.1 kWh
Dimensions L x W x H
19.0 x 14.5 x 28.3 cm
