4.2 Mounting of the Fuel Cell
Select a suitable location as described in Chapter 4.1,
paying attention to the dimensions in Chapter 3.3, page
13.
1. Secure the mounting plate tightly to the desired
location. Use proper screws and dowels, if
necessary, so that the mounting plate cannot shake
loose in case of an accident.
2. Place the unit onto the mounting plate. It is possible
to mount the unit in 2 possible directions.
3. Put the mounting bar at the screws of the mounting
plate.
4. Move the mounting bar to the fuel cell and then to
the right hand side. Adjust the mounting bar in this
position with the two mounting nuts.
