Part item
Important notes
 Please do not violently assemble during the assembly process, if you
are in trouble, you can call 0551-65536542
 When installing the hose, do not bend it excessively, otherwise it will
cause creases and affect the spraying effect.
 Be sure to connect the aircraft power supply after completing all
installation and connection.
Installation Please prepare medium-strength screw glue when installing. First complete
the unpacking inspection, and then install the landing gear, arm, motor system, and spray
system. If there are other options, install the options.
Front cover
6LQuick release tank
Frame
Back cover
Water pump and imitation radar support
Battery compartment
Extension rod nozzle (silicone )
Folding arms
Landing gear
X6 motor set
