EFT agriculture drone frame installation instruction
© 2019 EFT All right reserved
Spray system installation
Warning
During the installation process, please pay attention to safety. EFT will not be
responsible for any injuries and losses caused by improper operation.
1、Use M3*16 screws to fix the extension rod nozzle, place the X6 motor seat gasket under the
motor seat, and tighten the two M3*16 screws.
2、Use a 6mm water pipe to connect the extension rod nozzle, and the other end to
the built-in 6-6 pneumatic head of the frame.
