56-VOLT LITHIUM-ION CORDLESS 15" STRING TRIMMER14
UNFOLDING THE SHAFT (ONLY FOR ST1520S/ST1510S/ST1520S-FC/
ST1510S-FC)
WARNING:
In order to avoid pinching your hands or ngers, do not hold the
shaft at the joint.
WARNING:
Do not attempt to
start the trimmer until the shaft has been
locked.
1. Remove the battery pack from the
trimmer.
2. Put your trimmer on the ground or
the oor and make sure that the
cable is inside the shaft, so that it
will not be pinched when closing
the joints. Carefully unfold the shaft
until the two holes in the joint are
accurately aligned (Fig. 2).
3. Insert the bolt (supplied) and tighten
it with the supplied hex wrench to
lock the shaft in place (Fig. 3).
2
3
