MOUNTING THE GUARD
1. Lift the cutting head and face it downward; align the two
mounting holes in the guard with the two bolts that are
preassembled on the base of shaft. Make sure that the
internal surface of the guard faces towards the cutting
head (Fig. E).
2. Lock the guard in place with the bolts and the supplied
hex wrench (Fig. F).
REPLACE THE TRIMMER HEAD WITH THE 3-TEETH
BLADE
Know the trimmer head Fig. G and follow the steps as Fig.
H-1 - Fig. H-4 shown (refer to the section “line replace-
ment”) to disassemble the trimmer head. To mount the
blade follow the steps below:
1. To mount the metal blade unit (Fig. I).
2. Remove the guard accessory by loosening the three
screws with washer (Fig.J).
3. The blade is shipped with a sheath. Before mounting
the blade onto the brush cutter, the sheath should be
removed by undoing the clamp wire from the hook on
the sheath (Fig. K).
Fig. G-K parts description see below:
G-1 Inner Flange I-3 Flange Cover
G-2 Flange Cover I-4 3-teeth blade
G-3 Upper Housing
ASSY
I-5 Outer Flange
G-4 Washer I-6 Nut
G-5 Nut I-7 Slot in the Flange
G-6 Spring J-1 Line-cutting Blade
G-7 Wire Holder with
Trimmer Line
J-2 Guard Accessory
G-8 Lower Housing
ASSY
K-1 Clamp Wire
I-1 Motor Shaft K-2 Hook
I-2 Inner Flange
NOTICE: To protect against injury, you have to wear
gloves prior to any operation with the 3-teeth blade.
4. Rotate the motor shaft to align the slot in the inner ange
with the shaft-locking hole in the gear case (Fig. L)
5. Insert the hex wrench into the aligned holes to act as a
stabilizer (Fig. M).
Fig .L & M parts description see below:
L-1 Gear Case L-3 Motor Shaft
L-2 Aligned Shaft-locking
Holes
M-1 Stablizer
6. Mount the blade onto the motor shaft, ensuring
that the suface of the blade is ush with the
surface of the inner ange bulge. Mount the outer
ange and the nut (Fig. N). Pre-tighten the nut in a
COUNTERCLOCKWISE direction by hand.
Fig .N parts description see below:
N-1 Nut
N-2 Out ange
N-3 3-teeth blade
7. Position the gear case against a solid surface for
support. With one hand hold the brush cutter shaft
and the other hand grasp the multi-function wrench
to tighten the nut following the directional arrow icon
marked on the outer ange (Fig. O).
USE OF GUARD ACCESSORY
NOTICE:
When the brush cutter is equipped with a trimmer
head, the guard accessory must be mounted onto the guard.
Secure the guard accessory onto the guard by tightening
the three screws with the hex wrench due to the line-
cutting blade is equipped on the guard accessory. Failure
to comply could result in an overly long cutting line and
motor overload.
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.
WARNING: Always wear eye protection, along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
APPLICATIONS
You may use the brush cutter for the purpose listed below:
◾ With3-teeth metal blade: Cutting grass, weeds,
wild growth and scrub, thinning young stands with a
maximum stem diameter of 2cm.
◾ With Trimmer Head: Trimming grass and weeds from
around porches, fences and decks.
NOTICE: The tool is to be used only for its prescribed
purpose. Any other use is deemed to be a case of misuse.
