56V LITHIUM-ION CORDLESS CHAIN SAW44
In addition, the guide bar has a sprocket
at its tip. The sprocket must be lubricated
weekly with a grease syringe to extend
the guide bar life. Use a grease syringe to
lubricate weekly with chain oil by means
of the lubricating hole (Fig. 38). Turn the
guide bar and check that the lubrication
holes and chain groove are free from
impurities.
Reversing The Guide Bar
1. Remove the guide bar and chain
from the chain saw, following the
section: “REPLACE THE BAR AND
CHAIN”.
2. Remove the chain from the guide
bar and turn the guide bar over
(Fig. 39). The bottom of the bar will
be on the top.
3. Replace the chain on the bar.
4. Reassemble the guide bar and chain on the chain saw and adjust the chain
tension, following the section: “REPLACE THE BAR AND CHAIN” and
“ADJUSTING THE CHAIN TENSION”.
TRANSPORTING AND STORING
Do not store or transport the chain saw when it is running. Always remove the
battery pack before storing or transporting.
Always place the guide bar sheath on the guide bar and chain before storing or
transporting the chain saw. Use caution to avoid the sharp teeth of the chain.
Clean the chain saw thoroughly before storing. Store the chain saw indoors, in a
dry place that is locked and/or inaccessible to children.
Keep away from corrosive agents such as garden chemicals and de-icing salts.
39
38
Lubricating Hole
Sprocket in
Guide Bar Tip
