4. Carefully remove PCBA (including main switch, brake switch, battery connection terminals, PCBs,
capacitor and cables) from the housing.
Replace PCBA
12
Brake Switch
Battery Connection Terminals
Main Switch
PCBA
PCBA
Capacitor
Magnet Ring
