31
21. Assemble the guide bar and saw chain:
(4) Close the side cover and tighten the side cover knob by turning it clockwise.
(5) Remove all the sawdust from the chain by turning the chain tensioning knob clockwise until
the chain seats snugly against the guide bar with the drive links in the guide bar groove.
(6) Tighten the side cover knob securely.
• Follow the instructions in operating manual for detailed assembly and chain tension adjustment
procedures.
Assemble the Product
Side Cover Side Cover Knob
Chain Tensioning Knob
