7. Mount a new protective cap onto the self-propelled unit shaft as well as the wave washer. Fix the
cap by tightening the screw with spring washer and plain washer. The recommended torque is
1.8-2.5Nm.
NOTICE: The wave washer mustn’t be omitted in this step.
8. Mount the wheel assembly onto the self-propelled unit and fix it by tightening the hex bolt. The
recommended torque is 3.5-5Nm.
9. Insert the hubcap into the wheel.
1. Rear Wheel Replacement
8
LM2120E-SP Lawn Mower
