EGO POWER Plus ZT5200L - Page 71

7156-VOLT LITHIUM-ION ELECTRIC ZERO TURN MOWER — ZT5200L/ZT5200L-FC
LCD
Display
Description
Fault code
on LCD
Mower
Status
Indicator
Audio
Indicator
Cause Solution
see “Fault
code”
Battery Box Assembly not
functioning.
217 n/a one beep
The power
source from
Battery Box
assembly is
broken. The LED
headlights and
USB wiil not
work.
Have repairs performed by a qualied
service technician.
310/410 OFF one beep
The connection
between Type C
wires of Battery
Box assembly
and other Type
C wires of the
mower is out of
work.
Have repairs performed by a qualied
service technician.
201/202/203 OFF one beep
The BMS of
the Battery Box
assembly is
broken.
Have repairs performed by a qualied
service technician.
see “Fault
code”
Start/stop Switch Fault 314/414 OFF one beep
Switch PCBA
failure or bad
wire connection
for Start/stop
Switch.
Have repairs performed by a qualied
service technician.
see “Fault
code”
LCD Screen Fault 315/415 OFF one beep
LCD assembly
is broken or bad
wire connec-
tion of the LCD
assembly.
Have repairs performed by a qualied
service technician.
