56 VOLT LITHIUM-ION COMMERCIAL CORDLESS LINE TRIMMER — STX4500
13
nut. Make sure that the loop handle is positioned
upwards and points toward the top of the rear handle
(Fig. D4).
7. Pull the quick-release lever up to move/rotate the loop
handle to a comfortable operating position (Fig. D5).
8. Fold the quick-release lever to secure the loop handle
in place (Fig. D6).
WARNING: Never operate the machine without the
loop handle firmly in place.
REPLACE THE TRIMMER HEAD WITH THE BRUSH
CUTTER HEAD
1. Remove the battery pack from the machine
2. Rotate the trimmer head to align the slot in the flange
with the shaft-locking hole in the gear case and insert
a stabilizer into the hole (Fig. E1).
3. Rotate the trimmer head CLOCKWISE to remove it from
the motor shaft (Fig. E1, E2).
4. The blade is shipped with a sheath. Before mounting
the blade onto the brush cutter, the sheath should be
removed from the hook on the sheath (Fig. E3).
NOTICE: To protect against injury, you have to wear
gloves prior to any operation with the 3-tooth blade.
5. Mount the inner flange and flange cover into its place,
if they had separated from the shaft (Fig. E4).
6. Mount the blade onto the motor shaft, ensuring that
the surface of the blade is flush with the surface of the
inner flange bulge. Mount the outer flange and the nut
(Fig. E5). Finger-tighten the nut COUNTERCLOCKWISE.
7.
Position the gear case against a solid surface for
support.
With one hand hold the brush cutter shaft and
the other hand grasp a 16 mm socket wrench (not
included) to tighten the nut COUNTERCLOCKWISE
(Fig. E6).
8. Remove the line trimmer guard by loosening the two
bolts with washers (Fig. E7).
9. Install the brush cutter guard (not included) with the
two bolts and washers from the line trimmer, the same
way as line trimmer guard (Fig. E8).
NOTICE: When the machine is equipped with the brush
cutter head, be carefully to choose the correct guard.
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
WARNING: Always wear eye protection, along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING: To prevent serious personal injury,
remove the battery pack from the machine before
servicing, cleaning, changing attachments or removing
material from the unit.
APPLICATIONS
You may use this product for the purposes listed below:
Trimming: used for removing grass and weeds up against
walls, fences, trees and borders.
Cutting: used for cutting the grass that is difficult to
reach using a normal mower.
NOTICE: The machine is to be used only for its prescribed
purposes. Any other use is deemed to be a case of
misuse.
