56 VOLT LITHIUM-ION COMMERCIAL CORDLESS LINE TRIMMER — STX450014
ATTACHING/DETACHING THE BATTERY PACK
Fully charge before rst use.
To Attach (Fig. F1)
Align the battery ribs with the mounting slots in the
machine battery port and slide the battery pack until it
snaps into position.
To Detach (Fig. F2)
Depress the battery-release button and the battery pack
will disengage from the latch.
WARNING: Always be aware for the location of your
feet, children, or pets when pressing the battery-release
button. Serious injury could result in if the battery pack
falls. NEVER remove the battery pack at a high location.
MOUNTING THE SHOULDER STRAP AND HOLDING
THE MACHINE
Depress the carabiner to open it and attach it onto the
carrying eyelet (Fig. H1).
For safe and better operation, put on the shoulder strap
across the shoulder as Fig. H2. Adjust the shoulder strap
in a comfortable operating position. Hold the machine with
both hands: One hand on the rear handle and the other
hand on the loop handle. The trimmer head should be
parallel to the ground so that it easily contacts the material
to be cut without the operator having to bend over.
There are two ways to release the strap. Take it away from
your shoulder directly (Fig. H3) or press the hook of the
strap and take it apart from the carrying eyelet fixed on the
shaft (Fig. H4).
WARNING: The shoulder strap is also a quick
release mechanism in a hazardous situation. When
an emergency occurs, take it off from your shoulder
immediately, no matter what way the strap is in.
WARNING: When wearing the strap, no other
wearable should interfere with the release and removal
of the strap.
WARNING: You should not use the single-shoulder
strap and double-shoulder strap simultaneously.
STARTING/STOPPING THE MACHINE (Fig. J)
To Start
1. Move the lock-off lever forward and then press the
trigger switch to start.
2. Different pressure on the trigger results in variable
rotating speed of the cutting unit. Adjust the speed to
suit the task at hand.
NOTICE: The motor starts only when the lock-off lever is
moved forward and the trigger switch is depressed at the
same time.
To Stop
Move the machine away from the cutting area and release
the trigger switch to stop it.
WARNING: Always remove the battery pack from the
machine during work breaks and after finishing work.
CHANGING SPEED MODE (FIG. K)
The machine features three speed modes.
Every time press the speed mode switch, the speed mode
will change.
The speed indicator will display the active speed status:
one light for low speed, two lights for medium speed,
three lights for high speed. The low speed mode provides
better control of the machine and longer operating time
per charge.
NOTICE:
The speed mode can be set before the machine is turned
on OR during operation.
When the machine is re-started after a break, the speed
mode will return to the previous speed.
BATTERY-STATUS INDICATOR AND SPEED
INDICATOR (FIG. K)
The battery-status indicator shows the charge level and
the working status of the battery pack, and the speed
indicator shows the working status of the machine as
shown in the chart below. The battery-status indicator
and the speed indicator will illuminate when the machine
is started OR the speed mode button is pressed.
