BOILER CONTROL PANEL
OFF
0
30
40
1
3
5
2 4
Front Control Panel LED introduction;
[1] - Power Indicator
[2] - Boiler Operation Indicator
[3] - Heat Call Indicator
[4] - Low Water Indicator
[5] - On/Off & Temperature Dial
User instructions,
TheControlpanelislocatedontheoutsideboilercover.Itconsistsofadualpurposedialthatallowsyouto
selecttheboilerOutputTemperatureorSwitchtheBoilerOnorOff.Toswitchtheboiler“Off”Yousimplyturn
thedialAnticlockwisetothe“Offposition.”Indicator(1)willashandtheboilerwillshutdownandstopheat-
ingthesystem.Thepumpwillrunforafurther90secondsthenturnoff.Iftheboilerisleftintheoffposition
thecontrolsystemwillrunthepumpperiodicallytopreventsystemfailure.
Toswitchtheboiler“On”simplyturnthedialClockwisetoyourdesiredtemperaturesettinggenerallyaround
65degC.Theboilerwillnowsitinstandbywaitingforacallfromtheexternalcontrolstoreandheatthe
systemwhenrequired.
LED Functions and Fault Finding
FUNCTIONS
ON-OFF
STAND-BY
BOILER
HEATING
CALL FOR
HEAT
WARNING
INDICATOR
All LED’s Off
CheckthatMainPowerisON?
Check–WT3OverHeatStat?IfWT3
requiresre-setinginvestigatethecause!
off
off
off
off
Boiler is ON
WaitingforCallfromexternalcontrols.
on
off
off
off
Boiler is ON and running.
ExternalControlsareCallingforheat
on
on
on
off
Low Water Level
TopupHeatingSystemWaterLevel.
off
off
off
on
Temperature Sensor Failure.
Theboilerwillstillheatiftheinletsensorhas
failedbutnottheoutletsensor!
ReplaceBothSensors.
Overheatingcanbepossible(“MaxInlet
temperaturereached”-condition).Controller
decreaseapowerinthissituation.
off
ashing
off
on
Max Inlet Temperature reached.
Nodemandfromsystem.
on
off
ashing
off
Boiler Off
LEDwillashfor90secondsuntilthepump
stops.
ashing
off
off
off
Figure 3
