EHC SLIMJIM - Technical Specifications; Boiler Range Specifications

18
GB-063C_f.615
EHCPartNumber:
EHCSJIM
4KW
EHCSJIM
7KW
EHCSJIM
10KW
EHCSJIM
12KW
EHCSJIM
14.4KW
Boilerrange kW 4kW 7kW 10kW 12kW 14.4kW
Pipeentryboilers-flow top
Pipeentryboilers-return bottom
Centralheatingflow&return
pipes
mm 22
Maxpressure bar 3
Min.pressure bar 0,5
Outflowwatertemperature °C 30÷80
Max.watertemperature °C 100
Overalldimensions(heightx
widthxdepth)
mm 912x203x172
Weight kg 11
Waterconnection mm 22
Safetyclass IP22
Electricalsupply VAC 240V1ph50Hz
Loadcurrent A 16,7 29,2 41,7 50,0 60,0
Minimumpermittedcablediameter mm 6 10 16
Heatoutput(Btu/h)
BTU/h 13648 23885 34121 40946 49135
Temperaturesetting(factoryset) °C 80
Min.temperaturesetting °C 30
Overheatprotection °C 100
Protection A 20 40 50 63 80
TECHNICAL SPECIFICATION
