12. System types
 The“SlimJim”boilerrangecanbeusedinvarioussystemdesignsincludingunderoorsystems.There
aretwoheatingschematicsonpage10Figure1&2thatillustrateanIndirectSystem(SPlan)&Direct
System(HeatingOnly).
 WerecommendtheuseofThermostaticRadiatorvalvesonallradiatorsexcludingthebypassradiator;this
radiatorshouldbettedwithlockshieldvalvesandleftinthefullyopenposition.Inadditionwerecommend
thatanautomaticbypassisusedinzonedsystemsandsettotherelevantowratesrequiredforthe
systemdesign.(Thebypassradiatorshouldbeaminimumsizeof600mmx600mmsingleconvector
orequalto2500Btutobeinstalledwithintheheatingcircuitandlockedopen.Thiswillbelocatedinthe
sameareaastheroomthermostat).

!
The system design should meet all current building regulations in force at the time of installation.
13. Hanging the Boiler
1 Takecarewhenremovingtheboilerfromitspackaging.Donotopenwithsharpobjectsasthismay
damagetheunit.
2 Hangtheboilerinaverticalpositionusingthetemplateandscrewsprovidedwithintheboilerpackaging.
Takecaretoleavealltherecommendedclearancesasshownintheschematicdrawingbelow.
3 AClearanceofapprox400mmatthefrontoftheunitisrecommendedtoallowaccessforanyfuture
maintenancethatmayberequired.
INSTALLATION
M4x8
M4x8
C
D
D
C
130
35
780
850
200
203
765
130
min.300
min.50
min.50
Front Cover Fixing Screws Boiler Dimensions & Fixing Positions
