Orientation of RadioLINK bases
It is best practice to align all the RadioLINK bases in the same direction as shown in the
diagram above. This will ensure that all the antennas are in parallel which will maximise
the RF signal strength.
Orientate
Latch to
point to
front wall
Orientate all RadioLINK bases in the same direction
Front Wall Front Wall
RadioLINK Base
LED
Antenna
RadioLINK Base
LED
Antenna
