5. TROUBLESHOOTING THE RF LINK
If when checking the RadioLINK interconnection some of the alarms do not
respond to the button test, then:
(i) Ensure you have held the test button down for up to 20 seconds and the amber
light has come on continuously for 3.5 seconds.
(ii) If you have de-activated the Repeater function on a unit, try re-activating the
Repeater on this unit and de-activating a different unit.
(iii) Extend the flexible antenna from the base housing. To do this, the antenna
should first be removed from its groove in the base of the unit (see Figure 10).
Remove the breakaway section in the outer rim and push the antenna in to this
groove. For improved signal strength the antenna can be pushed flat or vertical with
respect to the ceiling (see Figure 11).
12
Figure 10
Figure 11
