On/Off switch (4)
Infinitely variable speed control is possible with the
On/Off switch. The further you press the switch, the
higher the speed of the battery-powered
drill/screwdriver.
Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.
Technical data
Voltage supply 18 V =
Speed 0-400/0-1200 rpm
Torque 16 levels
Forward and reverse rotation yes
Chuck clamping width 0,8 - 10 mm
Battery charging voltage 18 V =
Battery charging current 2 A
Mains voltage for charger 230 V ~ 50 Hz
Sound pressure level LPA: 68,1 dB(A)
Sound power level LWA: 81,1 dB(A)
Vibration a
–
w
< 2,5 m/s
2
7
GB
