protected. Unauthorized persons are to be kept
away from the welding work.
2. The walls in the immediate vicinity of stationary
workplaces should not have a light color or a
sheen. Windows up to head height are to be
protected against radiation passing through them
or reflecting off them, for example by coating
them with a suitable paint.
Do not store or use the equipment in wet
conditions or in the rain. Use the
equipment only indoors.
2. Layout and items supplied (Fig. 1-8)
1. Carrying strap
2. Thermostat control lamp
3. Housing cover
4. ON/OFF switch
5. Welding wire speed controller
6. Switch for welding current adjustment
7. Mains plug
8. Earth terminal
9. Hose package
10. Welding nozzle
11. Burner
12. Fastening screw for housing cover
13. Welding screen
14. Burner switch
2.1 Assembly material
k. 1 x Safety glass frame
l. 1 x Welding glass
m. 1 x Transparent safety glass
n. 2 x Safety glass retaining bushes
o. 3 x Nut for handle
p. 3 x Screws for handle
q. 2 x Safety glass retaining pin
r. 1 x Handle
s. 1 x Welding screen frame
3. Intended use
The flux cored welding set is designed for self-
shielding flux cored welding using suitable wire. The
additional application of gas is not required.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains connection: 230 V ~ 50 Hz
Welding current: 45-90 A
Duty cycle X% 10 60
Welding current I
2
(A): 90 45
Idling voltage: 31 V
Max. welding wire drum: 0.4 kg
Welding wire diameter 0.9 mm
Fuse: 16 A
Weight: 14 kg
10
GB
