After completing the cut, switch off the saw
again.
6.2. Using as a crosscut saw
Set the saw to crosscut mode (see 5.2.1)
6.2.1 Settings (Abb. 2/3)
•
When the tightening screw (22) is loosened,
you can tilt the machine head to the left by up
to 45°.
•
The turntable (8) can be adjusted from -45° to
+45° by undoing the locking screws.(10)
•
Start the saw by pressing the On/Off switch
(3). The switch must remain pressed during
the sawing work.
6.2.2 Crosscut 90° and turntable 0°
(Fig. 2-3/23)
•
Press the On/Off switch (3) to turn on the saw.
•
Important. Place the material for sawing firmly
on the machine surface and secure it with the
clamp (37) to prevent it from moving during
the sawing process.
•
When you have switched on the saw, wait
until the saw blade (5) has reached maximum
speed.
•
Press the release lever (1) and, using the
handle (2), apply steady and light downward
pressure to move the machine head through
the workpiece.
•
After the cutting process is finished, bring
the machine head back to its upper (home)
position and release the ON/OFF button (3).
Important. The integral resetting springs will
automatically lift the machine head. Do not
simply let go of the handle (2) after cutting,
but allow the machine head to rise slowly, ap-
plying slight counterpressure as it does so.
6.2.3 Crosscut 90° and turntable 0°- 45°
(Fig. 2-3/24)
The crosscut and miter saw with table can be
used to make right and left angular cuts of 0°- 45°
in relation to the stop rail.
•
Move the machine head to its upper position.
•
Release the turntable (8) by slackening the
locking screw (10).
•
Using the handle (2), set the turntable (8)
to the desired angle, i.e. the marking (a) on
the turntable must coincide with the desired
angular setting (11) on the stationary base
plate (9).
•
Retighten the locking screw (10) to secure the
turntable (8) in place.
•
Cut as described under section 6.2.2.
6.2.4 Miter cut 0°- 45° and turntable 0°
(Fig. 2-3/25)
The crosscut and miter saw with table can be
used to make miter cuts of 0° - 45° in relation to
the work face.
•
Move the machine head to its upper position.
•
Fasten the turntable (8) in 0° position.
•
Undo the tightening screw (22) and use the
handle (2) to tilt the machine head to the left
until the pointer (b) coincides with the requi-
red angle value.
•
Retighten the tightening screw (22) and make
the cut as described in section 6.2.2.
6.2.5 Miter cut 0°- 45° and turntable 0°- 45°
(Fig. 2-3/26)
The crosscut and miter saw with table can be
used to make miter cuts to the left of 0°- 45° in re-
lation to the work face and, at the same time,
0° - 45° in relation to the stop rail (double miter
cut).
•
Move the machine head to its upper position.
•
Release the turntable (8) by slackening the
locking screw (10).
•
Use the handle (2) to adjust the turntable (8)
to the angle required (in this connection see
also section 6.2.3).
•
Retighten the locking screw (10) in order to
secure the turntable in place.
•
Undo the tightening screw (22) and use the
handle (2) to tilt the machine head (4) to the
left until it coincides with the required angle
value (in this connection see also point 6.2.4).
•
Screw the tightening screw (22) back down
again.
•
Cut as described under section 6.2.2.
6.3 Electric brake
For safety reasons, the equipment is supplied
with an electric brake system for the saw blade.
The equipment may therefore emit an odor or
generate sparks when it is switched off . This has
no in uence on the operational performance or
safety of the equipment.
