EINHELL TC-PG 1000 User Manual

GB
- 17 -
Tank capacity: ..................................................4 l
Consumption at 3/4 load ................ approx. 0,6 l/h
Weight: .....................................................16.5 kg
Sound pressure level LpA: ................. 68.7 dB(A)
LWA sound power level/KWA uncertainty
................................................ 90 dB(A) / 2 dB(A)
Spark plug: ......................................... LG F6RTC
Operating mode S1 (continuous operation)
The machine can be continuously operated with
the quoted power output.
Operating mode S2 (temporary operation)
The machine may be temporarily operated with
the quoted power output. Afterwards the machine
must be stopped for a while to prevent it from
overheating.
5. Before starting the equipment
Connecting to earth
The housing is allowed to be connected to earth
in order to discharge static electricity. To do this,
connect one end of a cable to the earth connec-
tion on the generator (Fig. 4) and the other end to
an external earth (for example an earthing rod).
6. Operation
Notice! Before using the appliance for the fi rst
time the tank must be fi lled with a petrol mixture
in a mixing ratio of 1:50. To do so, use the measu-
ring jug inside the tank. Shake the petrol mixture
before fi lling into the tank.
•
Check the fuel level and top it up if necessary
•
Make sure that the generator has sufficient
ventilation
•
Make sure that the ignition cable is secured to
the spark plug
•
Inspect the immediate vicinity of the gene-
rator
•
Disconnect any electrical equipment which
may already be connected to the generator
Mixture Regular un-
leaded Petrol
2- stroke - Oil
1:50
1 l 20 ml
2 l 40 ml
3 l 60 ml
4 l 80 ml
6.1 Starting the engine
•
Open the petrol cock (8) by turning it down
•
Move the ON/OFF switch (5) to position „ON”
with the key.
•
Move the choke lever (4) to position .
•
Start the engine with the reversing starter (7)
by pulling the handle forcefully. If the engine
does not start, pull the handle again.
•
Push the choke lever (4) back again after the
engine has started.
Warning!
When starting with the reserve starter, the motor
may recoil suddenly as it starts up, resulting in
hand injuries. Wear protective gloves when star-
ting the equipment.
6.2 Connecting consumers to the generator
•
Connect the appliance you want to use to the
230 V~ socket.
Notice! This socket may be loaded continuously
(S1) with 680W and temporarily (S2) for a maxi-
mum of 1 minutes with 800W. The generator is
suitable for 230 V~ a.c. appliances.
•
Do not connect the generator to the
household network as this may result in da-
mage to the generator itself or to other electri-
cal appliances in your home.
Note: Some electrical appliances (power jigsaws,
drills, etc.) may have a higher level of power con-
sumption when used in diffi cult conditions.
6.3 Switching off the engine
•
Before you switch off the generator, allow it
to run briefly with no consumers so that it can
„cool down”
•
Move the ON/OFF switch (5) to position
„OFF” with the key.
•
Close the petrol cock
Notice! The generator is equipped with an over-
load cut-out.
Anl_TC_PG_1000_SPK1.indb 17Anl_TC_PG_1000_SPK1.indb 17 07.12.2016 08:43:3007.12.2016 08:43:30

EINHELL TC-PG 1000 Specifications

General

Fuel type	Gasoline/oil mix
Motor type	Synchronous motor
Noise level	90 dB
Cooling type	Air
Maximum power	1200 W
Ignition system	-
Number of strokes	2
Fuel tank capacity	4 L
Engine displacement	63 cm³
Castor wheels	No
Product color	Black, Red

Weight and Dimensions

Weight	18600 g
Package depth	425 mm
Package width	355 mm
Package height	360 mm
Package weight	19700 g
