EINHELL TC-SM 2131/1 Dual User Manual

GB
- 23 -
Danger! Read the operating instructions to reduce the risk of inquiry
Caution! Wear ear-muff s. The impact of noise can cause damage to hearing.
Caution! Wear safety goggles. Sparks generated during working or splinters, chips and dust emitted
by the device can cause loss of sight.
Caution! Wear a breathing mask. Dust which is injurious to health can be generated when working on
wood and other materials. Never use the device to work on any materials containing asbestos!
Warning! The adjustable stop rails are secured by hex screws.
To make miter cuts (with the saw head inclined or the turntable set at an angle), the adjustable stop rails
must be fi xed at an outer position.
For 45° crosscuts to the left, the left stop rail must be pushed outwards and screwed tight.
For 45° crosscuts to the right, the right-hand removable stop rail must be removed in upwards direction.
To make 90° crosscuts, the adjustable stops rail must be fi xed at the inner position!
Caution! Risk of injury! Do not reach into the running saw blade.
Anl_TC_SM_2131_1_Dual_SPK9.indb 23Anl_TC_SM_2131_1_Dual_SPK9.indb 23 21.10.2019 09:47:1521.10.2019 09:47:15

EINHELL TC-SM 2131/1 Dual Specifications

General

Sliding rails	Yes
Stand material	-
Maximum capacity	- mm
Maximum weight capacity	- kg
Number of blade teeth	48
Input power	1500 W
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Idle speed (max)	4900 RPM
Miter setting (left)	45 °

Weight and Dimensions

Weight	11000 g
Package depth	455 mm
Package width	717 mm
Package height	393 mm
Package weight	14200 g
