EINHELL TC-SY 600 S User Manual

GB
- 25 -
8. Completely empty the container (12). Always
keep the container (12) free of residue and
check it for damage.
9. Use a rag soaked in solvent or water to clean
the outside of the paint spray gun and the
container (12).
10. Unscrew the air cap retaining ring (1) and
remove the air cap (2). Remove the nozzle
(3). Push the fl uid needle adapter (B) onto the
fl uid needle (13). Twist and pull to remove the
fl uid needle. Clean the air cap retaining ring,
air cap, nozzle and fl uid needle with a bristle
brush and solvent or water.
11. Remove the fi lter cap (16) to clean the air inlet
fi lter. Remove the fi lter and clean it by blowing
out with air. Replace the fi lter and screw the
fi lter cap onto the gun. Do not operate the gun
without the fi lter.
12. Reinsert the fl uid needle. Pull the trigger and
insert the nozzle on the fl uid needle. While
inserting, ensure that the pins on the sides of
the fl uid needle point up/down and not right/
left. Pull the trigger while placing the air cap
on the nozzle and tightly fasten the air cap
with the air cap retaining ring.
13. Ensure that the paint spray gun is completely
dry before storing it.
14. Properly dispose of residual paint and
cleaning agents in accordance with local laws
and regulations. Residual paint and solvents
must be taken to a suitable collection point. If
you are not sure, ask the local council where
the nearest collection point is.
Warning!
Never immerse the paint spray gun in water or
other liquids. The housing may only be cleaned
with a dampened rag.
Note: If you use 2-component paint, you must
clean the gun immediately. Otherwise the paint
may dry inside the gun, causing an equipment
fault.
8.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualifi ed electrician.
Danger! The carbon brushes should not be rep
laced by anyone but a qualifi ed electrician.
8.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
8.4 Ordering spare parts and accessories
Please provide the following information when
ordering spare parts:
•
Type of unit
•
Article number of the unit
•
ID number of the unit
•
Spare part number of the required spare part
For our latest prices and information please go to
www.isc-gmbh.info
Tip! For good results we
recommend high-quality ac-
cessories from !
www.kwb.eu
welcome@kwb.eu
9. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled. The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse. The equipment should
be taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of
such a collection point, you should ask in your
local council offi ces.
10. Storage
Store the equipment and accessories in a dark
and dry place at above freezing temperature. The
ideal storage temperature is between 5 and 30
°C. Store the electric tool in its original packaging.
Anl_TC_SY_600_700_SPK9.indb 25Anl_TC_SY_600_700_SPK9.indb 25 16.07.2018 16:56:2316.07.2018 16:56:23

EINHELL TC-SY 600 S Specifications

General

Capacity	0.8 L
Hose length	1.8 m
Product color	Black, Red
Adjustable strap	Yes
Spray gun purpose	Paint
AC input voltage	220-240 V
AC input frequency	50 Hz
Package depth	480 mm
Package width	570 mm
Package height	285 mm
Package weight	4050 g

Weight and Dimensions

Weight	3050 g
