GB
- 23 -
6.4 Mitre cuts 0°-45° and rotary table 0°-45°
(Fig. 8/13)
The crosscut saw can be used to make miter cuts
to the left of 0°- 45° in relation to the work face
and, at the same time, 0° - 45° in relation to the
stop rail (double miter cut).
•
Lift the machine head (4) to its top position.
•
Release the turntable (8) by slackening the
locking grip (10).
•
Adjust the rotary table (8) by its handle (2) to
the required angle (see also Section 6.2).
•
Retighten the tightening screw (10) in order to
secure the turntable in place.
•
Undo the tightening screw (12) and use the
handle (2) to tilt the machine head (4) to the
left until it coincides with the required angle
value (in this connection see also section
6.3).
•
Screw the tightening screw (12) back down
again.
6.5 Sawdust bag (Fig. 2)
The saw is equipped with a debris bag (14) for
sawdust and chips.
The debris bag (14) can be emptied by means of
a zipper at the bottom.
6.6 Replacing the saw blade (Fig. 1-6)
•
Before changing the saw blade: Remove the
power plug!
•
Wear work gloves to prevent injury when
changing the saw blade.
•
Swing the machine head upwards (4).
•
Undo the screw (z) on the cover plate (f) of
the saw blade.
•
Pull back the adjustable blade guard (6) and
at the same time turn the cover plate to achie-
ve access to the flange bolt.
•
Press the saw shaft lock (13) with one hand
while positioning the Allen key (d) on the
flange bolt (31) with the other hand. The saw
shaft lock (13) engages after no more than
one rotation.
•
Now, using a little more force, slacken the
flange screw (31) in the clockwise direction.
•
Turn the flange screw (31) right out and remo-
ve the external flange (32).
•
Take the blade (5) off the inner flange and pull
out downwards.
•
Carefully clean the flange screw (31), outer
flange (32) and inner flange.
•
Fit and fasten the new saw blade (5) in rever-
se order.
•
Important. The cutting angle of the teeth, in
other words the direction of rotation of the
saw blade (5) must coincide with the direction
of the arrow on the housing.
•
Check to make sure that all safety devices
are properly mounted and in good working
condition before you begin working with the
saw again.
•
Important. Every time that you change the
saw blade, check to see that it spins freely in
the table insert (22) in both perpendicular and
45° angle settings.
•
Important. The work to change and align the
saw blade (5) must be carried out correctly.
7. Replacing the power cable
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
8.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualifi ed electrician.
Important! The carbon brushes should not be re-
placed by anyone but a qualifi ed electrician.
