7
Connecting the 4.2V battery pack or 4.2V power source as shown in figure 2.2.a
below.
Front light control method is shown in figure 2.2.b
Connecting method of power source
Front light control
Figure 2.2.a
Figure 2.2.b
After connecting all the boards and accessories, your evaluation kits should look like
Figure 2.3 depending on the package you choose.
Please be noted that when connecting the EVK, always remember to connect the
power source first before connecting the USB to the computer.
Connected result of 6" Kaleido package
Connected result of 7.8" Kaleido package
Figure 2.3
