Eizo FlexScan EV2450 User Manual

- 16 -
Chapter 2 Basic Adjustment/Setting
2-3. Switching Display Modes (Color Modes)
This product is preinstalled with color modes for various display purposes.
Switch the mode according to the purpose and content for display. This allows the monitor to display images in a manner appropriate to the display content.
●
Display Modes
Color Mode Purpose
User1
User2
Select either of these modes to set a user-dened display mode.
sRGB
This mode is suitable for matching color reproduction with peripheral devices that support sRGB, such as when printing photos taken using a
digital camera.
Paper
This mode uses color tones and contrast similar to that of paper to produce a printed paper effect. It is suitable for displaying images from
media such as books and documents.
Movie
This mode displays moving images brightly and with a clear-cut three-dimensional appearance. It is suitable for playing back video content.
DICOM
Selected for the display in the DICOM mode.
Note
• “ScreenManager Pro” allows you to select the color mode automatically according to the application in use. (“ScreenManager Pro” is software for adjusting the screen using
the mouse and keyboard. This software can be downloaded from our web site (http://www.eizo.com).)

Eizo FlexScan EV2450 Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Separate H/V sync	Yes
Display technology	LED
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 81 kHz
Viewable size, vertical	296.4 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 68 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 6.0, EPEAT Gold (US), TUV/Ergonomics (including ISO9241-307), TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, WEEE, China RoHS, CCC, GOST-R
Product color	Gray
Market positioning	-
Compliance industry standards	RoHS
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	47 W
Power consumption (standby)	0.3 W
Power consumption (typical)	15.6 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	233 mm
Height (with stand)	473.5 mm
Weight (with stand)	6200 g
Depth (without stand)	47.9 mm
Width (without stand)	537.6 mm
Height (without stand)	317.6 mm
Weight (without stand)	3800 g
