Eizo FlexScan EV2450 User Manual

- 17 -
Chapter 2 Basic Adjustment/Setting
2-4. Conserving Energy
This monitor is equipped with EcoView functions to enable users to conserve energy.
Use this function to curtail unnecessary power consumption and save on electricity expenses. Saving power also reduces carbon dioxide emissions.
Note
• The power saving level (Power Reduction, CO
2
Reduction, and Eco Performance Level) can be checked on the “EcoView Settings” menu. The more indicators that light up
representing the Eco Performance Level, the higher the power saving level attained.
- Power Reduction: the reduction in the backlight’s power consumption as a result of the adjusted brightness value.
- CO
2
Reduction: converted from the “Power Reduction” value, this is an estimate of the quantity of CO
2
emissions reduced when using the monitor for 1 hour.
* The numeric value is a result of calculation based on a default setting (0.000555 t -CO2/kWh) determined by a Japanese ministerial ordinance (2006, Ministry of Economy,
Trade and Industry, Ministry of Environment, civil code article 3) and may differ depending on country and year.
Level of power saving

Eizo FlexScan EV2450 Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Separate H/V sync	Yes
Display technology	LED
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 81 kHz
Viewable size, vertical	296.4 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 68 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 6.0, EPEAT Gold (US), TUV/Ergonomics (including ISO9241-307), TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, WEEE, China RoHS, CCC, GOST-R
Product color	Gray
Market positioning	-
Compliance industry standards	RoHS
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	47 W
Power consumption (standby)	0.3 W
Power consumption (typical)	15.6 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	233 mm
Height (with stand)	473.5 mm
Weight (with stand)	6200 g
Depth (without stand)	47.9 mm
Width (without stand)	537.6 mm
Height (without stand)	317.6 mm
Weight (without stand)	3800 g
