Eizo FlexScan EV2736W User Manual

29
Chapter4PowerSavingFunctions
5. When “On” is selected, select “EcoView Sense Settings” for setting the details.
Item Setting Range Description
Time 5,30sec
1,3,5,10,15,30,45,
60min
Speciesthetimefromwhenapersonleavesthemonitoruntilthe
“NoPresencedetected”messageappears.Themonitorshiftsto
thepowersavingmodeabout20secondsafterthemessageis
displayed.
Sensitivity Level5
Level4
Level3
Level2
Level1
Whenthesettinglevelishigh(“Level5”atmaximum),evenminor
movementsofapersonaredetected,causingthemonitortoshift
tothepowersavingmodeonlyinfrequently.Ontheotherhand,
whenthesettinglevelislow(“Level1”atminimum),onlymajor
movementsofapersonaredetected,allowingthemonitortoshift
tothepowersavingmodefrequently.EcoViewSenseisactivated
whenthesensoronthefrontsideofthemonitordetectsthe
movementofheat.Therefore,thesensitivityshouldbechanged
dependingonthetypicaluser’sclothesorthetypicalroom
temperature.Ifthemonitorshiftstoorrecoversfromthepower
savingmodecontrarytoyourexpectations,trychangingthesetting
level.
Reset - Thisfunctionresetsalladjustmentstothedefaultsettings.
Note
• When the monitor is used in the “Portrait” direction, the detection sensitivity is lower than the “Landscape” direction.
Try increasing the sensitivity setting value when switching the mode to the power saving mode.
• To use the monitor comfortably, increase the sensitivity for high temperatures, which reduces the detection sensitivity,
and reduce the sensitivity for low temperatures, which increases the detection sensitivity.

Eizo FlexScan EV2736W Specifications

General

3D	No
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Response time	6 ms
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.6 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1440
HDCP	Yes
USB hub version	2.0
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
Power consumption (max)	67 W
Power consumption (standby)	- W
Power consumption (typical)	24 W
Power consumption (PowerSave)	0.5 W
Certification	TCO Displays 6.0, ECO Sense Gold, ISO9241-307, TUV/GS, c-Tick, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, GOST-R
Product color	Gray
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (without stand)	65 mm
Width (without stand)	640 mm
Height (without stand)	379 mm
Weight (without stand)	7300 g
