1 INSTALLATION
What is Resolution?
Resolution is expressed as the number of dots (pixels) displayed on the screen. A
larger number of dots produces a more sharply defined (a higher-resolution) image.
Note that for a given screen size the dot size decreases as the number of dots
increases: a 640 × 480 (dot × line) resolution uses larger pixels than a 1024 × 768
resolution. The display size of a given font therefore varies according to the
resolution. Higher resolutions allow you to display more information on the screen.
Horizontal Scan
Frequency
30-130
(kHz)
1-3. Setting the resolution
The following look-up table shows the maximum (Non-interlaced) vertical refresh
rates for this model with regard to standard resolutions set forth by VESA. The best
way to see if the monitor will work with a given resolution and rate, is to compare the
vertical refresh rate of the graphics board to the monitor’s range (Refer to the graphics
board manual for specifications). If the refresh rate is within the specified range of the
monitor, it should operate properly.
Maximum Vertical Refresh rate (Hz)
640×480 160
800×600 160
1024×768 160
1280×1024 121
1600×1200 104
1600×1280 97
1880×1440 86
1920×1440 86
2048×1536 80
