SMS Gateway User Manual
Shenzhen Ejoin Technology Co.,Ltd. 11
Figure 3.2-1 WAN Settings
Static IP: manually set up gateway IP.
Dynamic IP: automatically get IP from local network.
PPPoE: need ISP offer the account and password. Use this mode
when there is no router in the local network
The WAN IP address of gateway
The subnet mask of gateway
Default gateway IP address. Example: router IP.
Domain name server IP address. Example: 8.8.8.8.
Table 3.2-1
