Ejoin ACOM664 - 3.8.3 Media Statistics

SMS Gateway User Manual
Shenzhen Ejoin Technology Co.,Ltd.
61
3.8.3 Media Statistics
Media statistics shows the RTP information when send calls.
Figure 3.8.3-1 Media Statistics
Items
Description
Port
Number of GSM/CDMA/WCDMA/LTE ports.
Codec
The voice codec of current call use, g729, g723, g711 etc.
Remote IP:Port
The remote server rtp ip and rtp port
Local Port
Device rtp port
Txp kts/Bytes
Device->>server rtp packets
Tx Rate/Bytes
Device->>server rtp sending rate
Rxp kts/Bytes
Server->>device rtp packets
Rx Rate/Bytes
Server->>device rtp sending rate, 0 means mobile side can’t hear voice.
Figure 3.8.3-1 Media Statistics
