4.3 “Touch” control operation
The “TOUCH” control works by touching the screenprinted key (exclusively use your fingers and
no other utensils such as knives, forks, or other objects in general).
All oven functions are activated in this way. To make use of the control panel easier, only the keys
that may be activated are lit.
4.3.1 Switching on/off
Keep your finger on the “START/STOP” key for a few seconds and the display will show
the screen with the “EKA” logo, DATE/TIME. After 5’’ the screen dissolves and the oven
automatically readies for programming the cooking cycle: the “TIME” parameter screen is
displayed.
After 10 minutes if no key is activated, the “Touch” control goes into STAND-BY mode and only
the “START/STOP” key remains lit on the control panel.
To reactivate the “Touch” control, just touch the “START/STOP” key with your finger for
a few seconds. To activate the STAND-BY mode hold your finger on the “START/STOP”
key for a few seconds.
4.3.2 Manual operation
4.3.2.1 General information
The cooking cycle may be programmed by using the PARAMETER SCREEN (displays the value of
each individual parameter of the cooking cycle), or using the OVERVIEW SCREEN (simultaneously
displays all the cooking cycle parameter values). The PARAMETER SCREEN is displayed
automatically only when the cooking cycle is first set, after the oven is first switched on. In this
case the values of the parameters set must be confirmed by acting on the “SELECT” key.
In the OVERVIEW SCREEN the individually displayed parameter may also be selected. Choose the
parameter to be displayed with the “STEP” key, then touch the “SELECT” key and the
PARAMETER SCREEN is displayed.
The set value is automatically confirmed after 5’’ both in the OVERVIEW SCREEN and in the
PARAMETER SCREEN.
The RED SCREEN indicates WARNING when, while setting a step of the cooking cycle, the
parameter required to activate the step is missing (symbol in the direction of the number of
the step where the
operative parameter is missing) or the oven door is opened during the cooking cycle.
The RED SCREEN indicates ALARM (sound) when faults occur during oven operation that prevent
cooking cycle continuation or automatic washing cycle (the type of fault is described and
represented by a symbol).
For the various types of alarm see the relevant paragraph 11.
4.3.2.2 Selection of cooking parameters
The following parameters may be set for each step of the cooking cycle (up to 9 steps):
1. Cooking time
2. Cooking chamber temperature
3. Core temperature
4. Delta T
5. Percentage (%) of humidity/steam activation
