2.1 Technical features
Models
EKF 611 CTC
EKF 611 CTC/0/048
EKF 611 CTC/0/037
EKF 1011 CTC
Overall dimensions:
height
(with feet)
679 mm
950 mm
width
500 mm
500 mm
depth
892 mm
892 mm
Weight:
65,4 kg
89 kg
Maximum load per tray GN1/1:
4 kg
Total load trays: GN 1/1:
24 kg
40 kg
Electrical power:
Convection
resistors
1
7,5 kW
2
7,5 kW
Maximum electrical power:
7,8 kW
15,4 kW
Electrical insulation class:
I
Casing protection degree:
IPX5
Water pressure:
kPa 100 – 200
Power supply voltage:
400V 3N
50/60 Hz
230V 3~ (60Hz)
230V~ 50/60 Hz
400V 3N
50/60 Hz
Power supply cable section:
5G 2,5
(5 x 2,5 mm
2
)
4G 4 (4x 4mm
2
)
3G 6 (3x6mm
2
)
5G 2,5
(5 x 2,5 mm
2
)
Power supply cable type:
H07RN-F
Power supply cable connection:
Tipo : Y
The noise level of the appliance in operation is less than 70 dB (A).
The “technical data” plate is located on the side of the appliance.
3. Instructions for the installer
The following instructions are aimed at the skilled installer for them to perform installation,
electrical and water connection operations in the most correct manner and according to the safety
regulations in force in the place of installation of the appliance.
The manufacturer shall not be liable for damage or harm to persons, pets or property arising from
installation errors. Nor are they responsible for any appliance breakage caused by faulty
installation.
3.1 Storage
In the event the appliance has been warehoused at temperatures below 0°C (maximum allowed –
5°C), it must be brought back to a temperature of at least +10°C before operating it.
3.2 Transport of the appliance
During transport the appliance must be left in its packaging in order to protect it from any
external damage.
The weight of the appliance must also be taken into account in order to prevent overturning.
3.3 Unpacking the appliance
Remove packaging before installation. It consists of a wooden pallet supporting the appliance and
a cardboard casing protecting it. Ensure the appliance has not undergone any damage during
transport; otherwise immediately alert your dealer and/or carrier.
3.4 Removal of the protecting film
Before using the appliance accurately remove the special film protecting the stainless steel
components, avoiding to leave glue residues on the surfaces; if required, immediately remove
them using an appropriate solvent of non flammable type.
3.5 Disposal of packaging
