1.3 Technical specifications
External overall dimension L x D x H
935 x 980 x 1070 mm
Weight
118 Kg
Nominal thermal capacity
13,50 kW
Tray maximal load GN1/1-600x400mm
4 - 2 kg
Total load GN 1/1-600x400mm
28 - 12 kg
ISO 7-1 gas union
1/2 “
Water union
3/4 “
Fume exhaustion vertical tube
Ø 150 mm; height min. 1000 mm
Appliance category
II2H3+
Factory adjustment
Methane gas G20 , 20 mbar
Type of construction
A
1
/ B
11
Electrical power
220-230 V ~
Electrical capacity
0,5 kW
Class
I
Power cable type
H07RN-F 3 x 1,5 mm
2
Connecting electric cable
Type Y
Gas connection pressure
Liquid butane/propane gas G30/G31 : 30/37 mbar
Methane gas G20: 20 mbar
Water connection pressure
Max. 200 kPa (2,0 bar)
Gas consumption calculated at low heat value of H
i
at
15° and 1013 mbar
G30 : 1,065 kg / h
G20 : 1,429 m
3
/ h
Parameters to the chimney B
11
(Ø 150 mm, L=1 m)
(G20 20 mbar)
fume load
31.45 g/s
fume temperature
163.5 °C
fume pressure
-2.8 Pa
Parameters to the chimney B
11
(Ø 150 mm, L=1 m)
(G30 28-30 mbar)
fume load
29.83 g/s
fume temperature
169.2 °C
fume pressure
-2.9 Pa
Main injector diameter
G30/G31 : 190 1/100 mm
G20 : 280 1/100 mm
Primary air bush adjustment
G30/G 31 : 16 mm
G20 : 10 mm
Table 1
The noise level of the appliance in operation is less than 70 dB (A).
2. General instruction (for installation technician)
The installation technician must make sure that start-up conforms to current national
regulations. The appliance must be installed only by qualified personnel authorised by the
manufacturer. She must observe the safety regulations in force in the country where the
appliance is installed. All extraordinary maintenance jobs (possible adaptation to another type of
gas or replacement of parts) must be performed by qualified personnel having the necessary
professional qualifications.
The protected devices and / or sealed by the manufacturer and that are not intended for
maintenance, adjustment, or adaptation to change of gas must not be handled either by the
installer or user.
The seals that must be removed to change the gas must be restored at the end of the
adaptation.
The manufacturer will not respond for damage to people, animals and property due to
installation errors. Likewise the manufacturer is not responsible for breakage caused to the
appliance by incorrect installation.
