ELAC Debut Reference DBR62 User Manual

SPECIFICATIONS
Model DBR62
Bookshelf Speaker
DCR52
Center Channel Speaker
DFR52
Floorstanding Speaker
Enclosure Type 2-Way Bass Reflex 2 - Way Bass Reflex 3-Way Bass Reflex
Frequency Response 44Hz - 35000Hz 55Hz - 35000hz 42Hz - 35000Hz
Nominal Impedance 6 Ohms 8 Ohms 6 Ohms
Sensitivity 86db @ 2.83v/1m 87db @ 2.83v/1m 87db @ 2.83v/1m
Crossover Frequency 2200Hz 2200Hz 90hz/2200Hz
Max Power Input 120 Watts 120 Watts 140 Watts
Tweeter 1" Cloth Dome 1" Cloth Dome 1” Cloth Dome
Midrange n/a n/a 5.25 Inch Aramid Fiber
Woofer 6.5 Inch Aramid Fiber 2 x 5.25 Inch Aramid Fiber 2 x 5.25 Inch Aramid Fiber
Cabinet CARB2 Rated MDF CARB2 Rated MDF CARB2 Rated MDF
Cabinet Finish White Bae, Oak Cabinet or
Black Bae, Wallnut Cabinet
White Bae, Oak Cabinet or
Black Bae, Wallnut Cabinet
White Bae, Oak Cabinet or
Black Bae, Wallnut Cabinet
Port Dual Flared 3 x Dual Flared 3 x Dual Flared
Binding Posts 5-Way Metal 5-Way Metal 5-Way Metal
Dimensions (WxHxD) 8.18” x 10.82” x 14.13” 20.74” x 9.52” x 7.28” 7.28” x 9.52” x 39.99”
Weight (lb / Kg) 18.07 / 8.2 22.26 / 10.1 36.81 / 16.7
ELAC Debut Reference Speakers | www.elac.com | Page 10

ELAC Debut Reference DBR62 Specifications

General

Enclosure Type	Bass Reflex
Tweeter	1-inch Cloth Dome
Nominal Impedance	6 Ohms
Max Power Input	120 Watts
Woofer	6.5-inch aramid fiber cone
Frequency Response	44Hz - 35kHz
Sensitivity	86dB at 2.83V/1m
Crossover Frequency	2.2kHz
Cabinet Finish	walnut
